Applicazione
The installation cables are used for telephone and signal transmission for permanent surface or concealed installation in dry and damp rooms, on or under plaster, and on external walls.
Norme
• DIN VDE 0815/DIN 57815
Costruzione
Conduttori
Solid annealed bare copper sized 0.6mm as per VDE 0295/IEC 60228 Class 1
Isolamento
PVC YI1 type to DIN VDE 0207-2
Elemento di cablaggio
Star Quads
Cavo Core Assemblea
Each 4 wires are stranded into a star quad, the quads are stranded to units and the units are stranded to form the core
Core Wrapping
One or more non-hygroscopic polyester tapes are helically or longitudinally laid with an overlap prior to sheathing
Schermo
Laminated aluminium foil is fully enclosing the core with an overlap
Guaina
PVC YM1 type to DIN VDE 0207 part 5
Ripcord
Nylon ripcord may be placed parallel to the cores to facilitate sheath removal
Drain Wire
Tinned drain wire applied longitudinally to provide continuity of the screen
Type Codes
J Installation Cable Y Polyvinyl Chloride (PVC) Bd Unit stranding.
Proprietà elettriche
Nominal Conductor Diameter |
mm |
0.6 |
VDE CODE |
|
J-YY |
Conductor Size |
mm2 |
0.283 |
Maximum Conductor Resistance @20°C |
Ω/km |
63 |
Minimum Insulation Resistance @500V DC @20°C |
MΩ.km |
100 |
Maximum Mutual Capacitance @0.8KHz |
nF/km |
100 |
Maximum Capacitance Unbalance @0.8KHz |
|
|
K1 max |
pF/100m |
300 |
K9-K12 max |
pF/100m |
100 |
Maximum Loop Resistance @20°C |
Ω/km |
130 |
Maximum Average Attenuation @0.8KHz |
dB/km |
1.7 |
Maximum Working Voltage Peak Value |
V |
300 |
Nominal Insulation Thickness |
mm |
0.2 |
Nominal Insulated Conductor Diameter |
mm |
1.0 |
Proprietà meccaniche e termiche
Temperature range during operation (fixed state): -30°C – +70°C
Temperature range during installation (mobile state): -20°C – +50°C
Minimum bending radius: 7.5 x Overall Diameter
Colore Codice
Quads
The single core is identified by black ring markings:
| Side Circuit 1 |
a-wire |
without marking |
| |
b-wire |
1 mark distance 17mm |
| Side Circuit 2 |
a-wire |
2 marks distance 34mm |
| |
b-wire |
2 marks distance 17mm |
Subunità
Basic colours for the wire insulation of the 5 star quads of a basic unit:
| Quad 1 Red |
Quad 2 Green |
|
| Quad 3 Grey |
Quad 4 Yellow |
Quad 5 White |
The tracer units are coded with a red helix, all other units by a white binder
Dimensioni e peso
VDE CODE: J-YY…x2x 0.6 Bd
| Cable Code |
Number
of
Pairs |
Nominal Insulation
Thickness
mm |
Nominal Sheath
Thickness
mm |
Nominal Overall
Diameter
mm |
Nominal
Weight
kg/km |
| 0.6mm Conductor, 1.0mm Insulted Wires |
TP815J-YY-Bd-2P06 |
2 |
0.2 |
1.0 |
4.5 |
34 |
TP815J-YY-Bd-4P06 |
4 |
0.2 |
1.0 |
6.5 |
59 |
TP815J-YY-Bd-6P06 |
6 |
0.2 |
1.0 |
7.0 |
74 |
TP815J-YY-Bd-10P06 |
10 |
0.2 |
1.0 |
8.5 |
111 |
TP815J-YY-Bd-16P06 |
16 |
0.2 |
1.0 |
10.0 |
160 |
TP815J-YY-Bd-20P06 |
20 |
0.2 |
1.0 |
11.0 |
200 |
TP815J-YY-Bd-24P06 |
24 |
0.2 |
1.0 |
11.5 |
224 |
TP815J-YY-Bd-30P06 |
30 |
0.2 |
1.2 |
13.0 |
284 |
TP815J-YY-Bd-40P06 |
40 |
0.2 |
1.2 |
15.0 |
364 |
TP815J-YY-Bd-50P06 |
50 |
0.2 |
1.2 |
16.5 |
451 |
TP815J-YY-Bd-60P06 |
60 |
0.2 |
1.4 |
17.5 |
529 |
TP815J-YY-Bd-80P06 |
80 |
0.2 |
1.4 |
20.3 |
700 |
TP815J-YY-Bd-100P06 |
100 |
0.2 |
1.4 |
22.3 |
850 |
